PRODUCT |  NEMESIS 9800 SERIES

  •  Product name : NEMESIS 9800 SERIES
  •  Category : Hardness Testers » Innovatest
  •  Catalog :

Description

NEMESIS 9800 SERIES

UNIVERSAL HARDNESS TESTER



Ideal for very large components!



Features :

- Brinell, Vickers, Knoop, Rockwell, Superficial Rockwell, HVT & HBT, Ball indentation for plastic ISO 2039/1

-Load cell, force feedback, closed loop system

-Load range 1Kgf - 250Kgf (9801), 3Kgf until 750Kgf (9802), 10Kgf until 3000Kgf (9803)

- Rockwell Scales: A, B, C, D, E, F, G, H, K, L, M, P, R, S, V, 15N, 30N, 45N, 15T, 30T, 45T, 15W, 30W, 45W, 15X, 30X, 45X, 15Y, 30Y, 45Y

- Vickers Scales: HV/10Kgf, 20Kgf, 30Kgf, 50Kgf, 100Kgf, 120Kgf;

- Brinell Scales: HB1/10Kgf, 30Kgf; HB2.5/15.625Kgf, 31.25Kgf, 62.5Kgf, 187.5Kgf;
HB5/25Kgf, 62.5Kgf, 125Kgf, 250Kgf, 750Kgf; HB10/100Kgf, 250Kgf, 500Kgf, 750Kgf, 1000Kgf, 1500Kgf, 3000Kgf;

- HVT Scales: HVT/5Kgf – 120Kgf;

- HBT Scales: HBT/5Kgf – 3000Kgf;

- Ball indentation for plastic ISO 2039/1 (scales depending on model)

- Motorized test head movement

- Descending test head with 6, 7 or 8 position turret, standard 3 indenters, 3 objectives

- Automatic hydraulic clamping of 3-axis

- 15’’ Industrial HD Touch screen, Embedded Powerful Fanless System Controller, 2x 80GB SSD data storage drive Windows 7 Embedded, RJ45 LAN, WLAN, USB, RS-232

- IMPRESSIONS™, full tester & configuration control, graphic indent simulation, test program setting for user defined test programs, large test results storage, 3 simultaneous conversions to other hardness scales, limit settings, advanced test report generator, CSV export, graphics display engine & many more functions

- Indent ZOOM function

- High accuracy depth measuring system

- Built-in driver pack for X-Y or Jominy stages

- Workpiece accommodation: maximum test height 1600mm, maximum depth 1500mm 2 times 180° rotation

- Meets or exceeds ISO, ASTM and JIS standards

- Wireless mouse and keyboard



(Please do not hesitate to contact us if you need brochures)
