Voltage LED steps

AC: 24, 48, 120, 208, 240, 277, 480, 600

DC: 6, 12, 24, 36, 48, 110, 220, 400

ACV frequency range

50/60Hz

LED enable input voltage

>4.5V AC/DC

Accuracy

-30% to 0% of the indication

Range selection

Automatic

Max measuring current

≤1.2mA (600VAC); ≤1.0mA (400VDC)

Display delay

LED indication <0.1s

Input Impedance

1MΩ (approx)

Continuity test

Range 0 to 400kΩ, guaranteed on < 50kΩ;

Low impedance test

12-250VAC/DC; impedance <6kΩ;

Operation time

30 seconds on / 10 minutes off duty cycle

Power supply

2 x "AAA" 1.5V alkaline batteries, 50mA max

Battery life

Approx. 8 hours of continuous use typical

Operating Temperature

-10 to 55° C (14 to 131° F)

Storage Temperature

-30 to 60° C (-22 to 140° F)

Operating Humidity

10 to 85% RH (non-condensing)

Operating Altitude

2000m (7000 ft.) maximum

Dimensions

240 x 78 x 40mm (9.4 x 3 x 1.6")

Weight

260g (9.2oz)
